Magnetite separator and fine filter for removing system impurities
Contamination in heating and cooling systems leads to wear and premature failure of pumps, valves and heat exchangers. The dual filter (magnetite and fine filter), magnetite separator and the innovative MAGella Side Stream Filter of our MAGella series protect your systems from all types of contamination. This saves heating system operators energy and costs and increases system efficiency.
Even small amounts of iron oxide or other impurities result in considerable efficiency losses and thus energy wastage. Magnetite filters from the MAGella series can remove almost 100 % of the black iron oxide sludge (magnetite) present as suspended matter in all central heating systems, as well as all other particles down to 1 µm. The filters “actively” catch the circulating dirt – this ensures year-round protection.
The MAGella Side Stream Filter
The innovative MAGella Side Stream Filter is a fully automatic filter unit (magnetite separator and fine filter) for cleaning and filtering heating systems. This ground-breaking technology sets new standards in the efficiency and thoroughness of system cleaning. It is particularly impressive due to:
More features
Magnetic field strength:
4 x 9.000 Gauß
Max. operating temperature:
100°C
Max. operating pressure:
3 bar
Inlet / Outlet:
3/4“ IG (MG 100)
1″ IG (MG 200)
1 1/4″ IG (MG 300)
Magnetic field strength:
6 x 12.000 Gauß (twister5)
11 x 12.000 Gauß (twister10)
Max. operating temperature:
80°C
Max. operating pressure:
10 bar
Inlet / Outlet:
1 1/2“ IG
Absolute fine filter:
1μm (0,001mm)
Magnetic field strength:
11 x 12.000 Gauß
Max. operating temperature:
80°C
Max. operating pressure:
8 bar
Inlet / Outlet:
1 1/2“ BSP G IG
Absolute fine filter:
1μm (0,001mm)
Magnetic field strength:
11 x 12.000 Gauß
Max. operating temperature:
80°C
Max. operating pressure:
6 bar
Inlet / Outlet:
1 1/2“ BSP G IG
Absolute fine filter:
1μm (0,001mm)
Smaller to medium
system sizes
Magnetite separator
Flow rate:
32 – 100 l/min
More features
Magnetic field strength:
4 x 9.000 Gauß
Max. operating temperature:
100°C
Max. operating pressure:
3 bar
Inlet / Outlet:
3/4“ IG (MG 100)
1″ IG (MG 200)
1 1/4″ IG (MG 300)
Medium to large
system sizes
Magnetite and fine filter
Flow rate:
5 – 10 m³/h
More features
Magnetic field strength:
6 x 12.000 Gauß (twister5)
11 x 12.000 Gauß (twister10)
Max. operating temperature:
80°C
Max. operating pressure:
10 bar
Inlet / Outlet:
1 1/2“ IG
Absolute fine filter:
1μm (0,001mm)
Large
system sizes
Magnetite and fine filter
Flow rate:
5 m³/h
More features
Magnetic field strength:
11 x 12.000 Gauß
Max. operating temperature:
80°C
Max. operating pressure:
8 bar
Inlet / Outlet:
1 1/2“ BSP G IG
Absolute fine filter:
1μm (0,001mm)
Medium to large
system sizes
Magnetite and fine filter
Flow rate:
10 m³/h
More features
Magnetic field strength:
11 x 12.000 Gauß
Max. operating temperature:
80°C
Max. operating pressure:
6 bar
Inlet / Outlet:
1 1/2“ BSP G IG
Absolute fine filter:
1μm (0,001mm)
Solutions for small-sized systems
The MAGella 100 magnetite separator is a compact magnetite filter for removing system contamination in heating and cooling systems. It removes all types of contamination that usually occur in these systems. It protects the boiler and helps to maintain optimum operation and efficiency of the system.
The MAGella MG 100 makes use of a unique magnetic core to maximise the contact time between the circulating contaminants and the powerful neodymium iron boron magnets. It is particularly suitable for systems with little space available. It has a compact design combined with a linear construction and a T-piece that can be rotated by 360°.
Small and compact
Circulating impurities in heating systems can lead to wear and premature failure of pumps, valves and heat exchangers. The MAGella MG 100 magnetite separator mounted on the boiler return line protects the system from all types of contamination.
Solutions for medium-sized systems
Built to automotive standards with a robust GRP housing, double seals and high-quality brass valves manufactured in the EU, the MAGella MG 200 offers you lasting quality with a 10-year warranty. It has a high separation capacity and is ideal for high flow rates.
The MAGella core reduces the water flow rate and turbulence within the filter to improve the retention of contaminants. It also ensures that the filter remains clog-free. The separated impurities can be easily flushed out of the system by removing the magnet and opening the drain valve on the lower part of the filter.
Compact and powerful
Circulating impurities in heating and cooling systems can lead to wear and premature failure of pumps, valves and heat exchangers. The MAGella MG 200 mounted on the return line on the boiler protects the system from all types of contamination.
Solutions for large-sized systems
The dual filters in the MAGella twister range are unique, highly efficient system filters for magnetic and non-magnetic contaminants in heating and cooling systems. They include an absolute fine filter up to 1 μm and one of the most powerful magnetite separators on the market. With its 11 x 12,000-gauss magnet, the MAGella twister 10 is probably the most powerful compact filter in the world.
The MAGella Side Stream Filter is a fully automatic filter unit with integrated MAGella twister and is used for the permanent filtration of water using the bypass method in heating systems. The flow rate is not affected by the bypass process. The device controls the flow rate via the integrated pump. The device is used for magnetite filtration as well as sludge and fine filtration of non-magnetic parts.
If the filter capacity, pressure or temperature is exceeded, an alarm is triggered and the appliance is switched off immediately. There is no better way to improve heating water quality.
Extremely powerful
The MAGella twister dual filters are the most powerful compact magnetite and fine filters on the market. The MAGella side stream filter can filter up to 5,000 liters of system water per hour. The Modbus RTU communication makes it possible to view all operating statistics with one click. In addition, the Side Stream Filter switches off automatically when the filter is full.
