Heaty Filtra Advanced № 2
Art.-Nr. 100453-FL / Ersatzfilter: 100451
Our Heaty Filtra Advanced filtration device removes dirt, solids and other deposits from the water. This prevents clogging of pumps or heat exchangers and promotes good heat transfer. In addition, material wear and the risk of germ formation are reduced.
Your advantages
- High flow rates
- 1μm fine filtration
- Simple operation
- Suitable for hot water
- Extraction tap for checking during operation
- Quick filter change
- Connection for pressure gauge
Scope of delivery
- Stainless steel filter housing
- Flow meter
- Shut-off devices
- Extraction tap
- 3x filter bag 1μm
- Quick-release fasteners at the inlet and outlet
- Hose set
- Dual filter MAGella twister10 (magnetic flux filter and fine filter)
- Hot water pump
These components are fully assembled on a large transport trolley with rubber tires and stair skids.
Heaven7 - UWS Cloud Portal
A new approach to digital system monitoring.
The UWS Cloud Portal brings together system information, measurement logs and system messages on a single central platform for the first time.
All data from the WaterBoy App is automatically documented in accordance with standards and can be accessed at any time. At the same time, intelligent Heaven7 devices such as the Racun series or replenishment solutions such as the Heaty Complete PROfessional deliver important information directly to the cloud – for example, in the event of leaks or when Vadion pH-Control mixed-bed resin has been used up.
This creates digital documentation of system statuses and operating data – clear, structured and available at any time.
measure – treat – replenish – document
One platform. All information. Maximum transparency.
Technical data
| Max. Filtration capacity at < 1μmg | 3.600 l/h |
| Max. Flow pressure | 6 bar |
| Magnetic field strength (Gauß) | 11 x 12.000 |
| Max. Operating temperature | 90 °C |
| Height / width / depth (approx.) | 1.170 / 480 / 470 mm |
| Power connection required | Yes, for pump |
